QSC Acoustic Design AD-S SUB
wqdq
QSC Acoustic Design AD-S SUB

I-Trust Systems

QSC Acoustic Design AD-S SUB

Dhs. 2,352.00 AED
colours
colours: Black

Details

Highlights:

  • AD-S SUB: The QSC Acoustic Design AD-S SUB is a powerful subwoofer designed for indoor use, delivering deep and impactful bass performance to complement the AD-S satellite speakers.
  • 6.5-inch Dual Voice Coil Woofer: The subwoofer features a 6.5-inch dual voice coil weather-treated paper cone woofer, providing clear and punchy bass response.
  • Wide Frequency Range: The AD-S SUB offers an effective frequency range of 45 Hz to 150 Hz, ensuring full-bodied low-frequency reproduction.
  • High Sensitivity: With a sensitivity of 86 dB at 1 W and 1 m, this subwoofer efficiently converts power into bass, delivering impactful and immersive low-end sound.
  • Omni Coverage: The subwoofer provides an omnidirectional coverage pattern, distributing bass evenly throughout the room for a seamless listening experience.
  • High SPL: The subwoofer can handle a maximum continuous SPL of 100 dB and a maximum peak SPL of 106 dB, ensuring powerful and dynamic bass performance.
  • Sturdy Construction: The subwoofer features a vinyl-wrapped medium density fiberboard enclosure and an ABS port baffle/cover panel, ensuring durability and protection.
  • Easy Installation: The included V-wall bracket, euroblock connectors, rear cover panel, and adhesive rubber feet make the installation process simple and convenient.


QSC Acoustic Design AD-S SUB

The QSC Acoustic Design AD-S SUB is a high-performance subwoofer designed to deliver rich and immersive bass response for various indoor applications. With its dual voice coil woofer and wide frequency range, it is an excellent addition to any AD-S satellite speaker system.



LF Transducer: 6.5-inch (165 mm) dual voice coil weather-treated paper cone woofer
HF Transducer: N/A
Effective Frequency Range: 45 Hz – 150 Hz
Rated Noise Power / Voltage: 100 W / 20 V (rms)
Sensitivity [dB] (rated @1 W, 1 m): 86
Coverage (-6 dB): Omni
Directivity Factor: TBD
Directivity Index [dB]: TBD
Maximum SPL [dB] (continuous / peak): 100 / 106
Recommended Amplifier: 100 W
Transformer Taps / Impedance: 70 V: 100, 50, 25, 12.5 W (mono only)
100 V: 100, 50, 25 W (mono only)
Bypass: 4 Ω mono or 8 Ω + 8 Ω stereo
Connectors: Hi-Z mono input: 4-pole Euroblock with thru output
Low-Z input: 4-pole Euroblock, left (mono) and right
Hi-pass mono output: x2 4-Pole Euroblock for x4 satellites
Enclosure Material: Vinyl wrapped medium density fiberboard
Port Baffle / Cover Panel: ABS
Ingress Protection: N/A
Operating Environment: Designed for indoor use
Operating Temperature Range: -4 to 122° F (-20 to 50° C)
Net Weight: 23.6 lb (10.7 kg)
Product Dimensions (Ø x H): 13.8 x 8.2 x 17-inch (350 x 209 x 432 mm)
Shipping Weight: TBD
Shipping Dimensions (H x W x D): TBD
Included Accessories: V-wall bracket, 4x euroblock connector, rear cover panel, adhesive rubber feet
