Paige 455200UE 16AWG-2C Stranded, Unshielded, PVC Cable

CABLE CONSTRUCTION

 1. Conductors

1.1 Material: Bare Copper
1.2 Size: 16 AWG
1.3 Construction: 19 Strand

 2. Insulation

2.1 Material: Polypropylene
2.2 Wall Thickness: .008”
2.3 Color code:
1-Black
2-Red

 3. Cabling Overall Lay

3.1 3” left hand lay

 4. Jacket

4.1 Material: PVC
4.2 Wall Thickness: .015”
4.3 OD: .174” nom.
4.4 Color: Gray
4.5 Ripcord under jacket
4.6 Markings: PAIGE #455200UE 16 AWG 2C (UL) TYPE CMR c(UL) TYPE CMG E191596
ROHS MADE IN USA (Ascending/Descending footage markers)

5. Electrical Properties

5.1 DC Resistance: 4.2 ohms/M ft.
5.2 Voltage: 300 Volts
5.3 Capacitance: (CDR-CDR) 23 pF/ft
